Laser input power: sealed co2 laser tube, average lifetime of laser air is 30,000 hours
Output power: 230V 50Hz/115V 60Hz, 1PH（10W）or 230V 50Hz/115V 60Hz1PH （30W）
consuming Power: 450W（10W）或700W（30W）
Operational environment : temperature 5-45℃(40-115°F)，humidity up to 80% (without congelation)
IP grade : IP50,NEMA 12/IP66,NEMA 4（as required）
Communication: USB/RS232/Ethernet 10 Base T
Axial encoder input:
Product detector input: NPN/PNP 24V detector
Input / output connective port: supply with system linkable set, remote on/ off, ready, marking, error signal.
SolMark Ⅱwork programming software application : Windows 9x, NT, 2000, ME, XP
Marking speed: 1600w/s , height 2mm, depending on lens and material
Lens type: LF2, LF3, LF4, LF5, LF8,
Range of inscription: 50*50、80*80、100*100、120*120、200*200.
Optional units
Apply to local duty creation/ modified contacting GUI control unit interface
Apply to local duty modifying control unit interface of letter keyboard
IP66/NEMA 4 encapsulation
Product detector and axial encoder
Air / powder assimilator (with active carbon filter)
Cooler with water-cooling system
